Wireless and wired CarPlay and Android Auto. Preserves all Toyota factory features.
- Install a module to add CarPlay and Android Auto functionality to your original screen.
- Easily switch between original Toyota OS and Hamilton OS.
- Preserves access to original XM, FM, and AM radios, as well as other Toyota factory features.
- Uses your original microphone for calls.
- Backed by Hamilton's talented technical support team for any assistance you need.
- This device supports Avalon vehicles with the APPS button on the left-side of the screen, as shown in the image (2015-2018 Toyota Avalon vehicles)
Upgrade your driving experience with the 2015-2018 Toyota Avalon Hamilton Upgrade Kit for CarPlay and Android Auto. This system, which has been engineered by Hamilton from the ground up, adds both wireless and wired CarPlay and Android Auto capabilities right into your Avalon’s factory display. The kit, carefully designed to integrate itself seamlessly with the original functionality of your Avalon, allows you to use your factory microphone, backup camera, and steering wheel controls. While the kit gives you the power of CarPlay and Android Auto, you can still switch back to your factory Toyota OS at any moment.
Access your original Toyota Interface with ease.
Hop right back from your new Hamilton OS to the original Toyota system by simply long-holding the voice speech button on your Avalon’s steering wheel for three seconds. Hamilton’s upgrade kit retains your system’s factory navigation, as well as your factory XM, FM, and AM radio.
Top-notch durability. Precision engineered in Raleigh, NC.
The Hamilton Upgrade Kit is levels above the competition thanks to elite manufacturing techniques and the use of genuine, high-quality internal components. The ARM-Cortez based processor logged an Automotive AEC‑Q100 Grade 3 rating, meaning it will work flawlessly no matter the climate, whether it be extreme heat or cold.
The Hamilton team designed the internal circuit board in Raleigh, NC, and it is gold-plated to ensure outstanding performance and durability.
Hamilton recruits first-class engineering talent with expertise in vehicle systems engineering. The Hamilton Upgrade kit was thoughtfully and skillfully designed to function without sacrificing any of your factory Toyota features. The kit uses your factory microphone, which allows for clear phone calls and conversations with Siri.
The Hamilton Guarantee. An unmatched warranty.
The 2015-2018 Toyota Avalon Hamilton Upgrade Kit is covered by the Hamilton Guarantee, our 3-year limited warranty. To learn more about this warranty, visit the warranty and support page on our website. At Hamilton, we treat every single customer how we would want to be treated.
| Components | Details |
|---|---|
| Operating System | HamiltonOS-25 |
| CPU |
ARM Cortex‑A7 CPU with N13 Co‑Processor with DDR3 RAM |
| Audio | DSP multi-channel I/O, I2S, ADC |
| Audio Routing | Uses Factory OEM Head Unit. No changes to audio quality |
| Video Decoder | MPEG‑1/2, MPEG4‑SP, full‑HD H.264 (1080p). Exceeds Toyota OEM Screen |
| Temperature Rating | AEC‑Q100 Grade 3 (-40c to +85c) |
| Heat Sink |
High Dissipation Hamilton Designed |
| Circuit Board (PCB) Technology | Designed in NC. HDI Technology. Precision plated for durability and performance. |
| Apple CarPlay | Wireless and Wired Compatibility |
| Android Auto | Wireless and Wired Compatibility |
| Microphone | Vehicle OEM |
| Compatibility Notes | Supports 2015-2018 Toyota Avalon vehicles. To verify your vehicle fits in this year range, your APPS button will be on the left side of your original screen (just like the one pictured in the Hamilton photos). |
CarPlay Overview and Setup
Frequently Asked Questions
Yes, we support both wireless and wired CarPlay and Android Auto. You can access your original factory OS at any time by long-holding your voice speech/menu button (this button may vary model to model; please check your pairing and setup video on our manuals page).
We employ some of the finest engineers in the world in this aftermarket CarPlay/Android Auto space. We do our testing here in the USA. This means we leverage our partnerships to locate American vehicles and gather all of our data off American cars. This way, we can be certain we do not disrupt factory equipment.
For our electronics, we use gold-plated PCB technology and premium components throughout. We use high quality harnesses and connectors to minimize the risk of damaging your wiring during installation and to protect against wiring faults. Also, we use a top-of-the-line reputable chipset that is specifically tailored for automotive applications.
You can use your factory radio channels and have CarPlay/Android Auto showing on your screen with the Hamilton Upgrade Kits with one important limitation: Please note that the factory radio channels are sealed channels. This means Siri cannot talk through these channels.
When you are streaming audio via CarPlay (e.g. Spotify, Apple Music, Sirius App, etc.), your music and Siri/Navigation will come out of your vehicle speakers mixed together.
However, while using the sealed factory radio channels, you will only be able to hear radio audio. System audio (Siri, navigation sounds, phone calls) cannot be mixed into the factory radio channels.
Note: You will not be able to use the AUX port for any external media devices liked DACs or MP3 players. The Hamilton Upgrade Kit consumes this audio input for CarPlay/Android Auto.
Playing audio via the factory USB port is not supported while using CarPlay/Android Auto. If you prefer USB, please use wired CarPlay/Android Auto.
Received this unit for my 2016 Toyota Avalon yesterday and I’m totally stoked, I already installed it (took roughly 4 hours) mainly because I was going step by step with the installation video and I had a small issue with one of the ribbon cable tabs coming off, but I called them and they totally saved my rear end! So far so good- still tinkering with it…. calibrating the screen and such BUT ITS ALREADY 1,000% better than the stock radio! I absolutely love it!!!!
The video instructions were great! My brother installed this in my daughter’s 2018 Toyota Avalon. He is very techy. I do think at times the instructions could have had a better angle on what the instructor was specifically talking about.
I installed the Hamilton CarPlay upgrade on my 2016 Toyota Avalon XLE. I have had it for about 2 weeks or about 250 miles. I feel like I can now post a proper review. To begin , this kit works in tandem with my plug and play amp that I had installed prior made by Beatsonic model ENA-2T1. When it comes to the installation, it was all pretty much like the instructional video but make sure you are EXTREMELY careful with the ribbon clips as one of them came off and it took me about 2 hrs to somehow get it back in place and get it to latch. Once installed back in my car ,I was delighted when CarPlay came on the screen!..it looks great and the resolution was better than I expected. I initially had touchscreen accuracy issues but found in the website help center how to calibrate the touchscreen and once I did, it made a huge difference! Now very accurate and precise touch input. Having lived with it daily for 2 weeks , I am very pleased with my purchase, well worth the money and the whole experience feels like it was from factory. Immediately made my car feel modern and inviting. If you have an Avalon and feel like the only thing missing is CarPlay…this is the way to go.
I just installed the system and it has been a absolute wonderful upgrade. I purchased a 2018 hybrid Avalon for the family to use. There a five drivers in my house, all Android users, and we all use this car at various time to take advantage of the fuel efficiency. Once everyone understood how it is integrated with the OEM controls, it quickly became second nature for ease of use. The best part is that it is wireless unlike two of my other Toyotas. In my earlier years I was my friends and families go to for car audio upgrades, so I was pretty comfortable doing the install. I do feel the video from Hamilton made that much more painless.
On a separate note, and this is not related to this product, but you might want to consider a digitizer upgrade from the OEM. I found the outer edges of the screen lacks the sensitivity needed what touching it, and is noted in several reviews of this make
We were unfortunately not able to use the product we purchased due to the specific system that was in the vehicle. However, the speedy response and excellent customer service we received from Hamilton will get me to come back once we get a new system. Thank you for your patience and attentiveness to our situation.
I bought this about 3 weeks ago for my 2018 Toyota Avalon. I followed the installation video/instructions, which were detailed and very easy to follow. I had it up and running a few hours later and once I disconnected the car's factory Bluetooth from my phone, it was smooth sailing. I still use my car's built-in backup camera, original touchscreen monitor, steering wheel buttons and media buttons and knobs. It's definitely the way to go if you're wanting to add Android Auto or Apple CarPlay to your car. I'm just so, so, so impressed! Hamilton Auto is an excellent business that I will recommend to anyone who's vehicle they cover!
Definitely the upgrade I was looking for Speed is good when switching from one screen to another with the functions I cannot complain definitely a five-star deal
This is a pretty great unit for retaining factory functionality and adding carplay. I have a 2016 Toyota Avalon Hybrid Limited with the JBL factory amplified system. With this plug-n-play unit I was able to retain all of my factory functions and sound system while adding carplay. The ribbon cable connections on the factory unit are very delicate and I had to disassemble the unit about 3 times to have them properly seated and connected to make the unit work. During the first couple days I noticed carplay would disconnect intermittently but worked about 80% of the time. I called into Hamilton's customer service and was called back very quickly and the representative stayed on the phone with me until my problems were resolved and went above and beyond in that regard. Since calling in I would say my unit is now working 98% of the time and I am very happy with it. I would recommend this unit to someone who wants to retain everything their factory system offers, while adding CarPlay.
I installed this myself and it was not too difficult. I usually use crutchfield to find a CarPlay solution for my cars but when I searched up my 2015 Avalon Limited, there seemed to be little options for the ones with JBL systems. I also did not want to sacrifice the OEM look. I eventually settled on an aftermarket Android unit that was made to look stock. It was great but had many issues with steering controls and echo on phone calls. Also would cause crackling in my speakers. I was happy to find this and got it working in a few hours. It seems to be responsive and all OEM features work. Also no crackling since it uses the stock radio! The downside is that the screen is smaller than the android unit and feels a bit cramped but I’m willing to sacrifice that in order to keep all original features. I do wish the resolution could be adjusted to make the interface look a little more crisp but understand that there are limitations with the outdated tech. Overall a great product if you are looking to keep your original equipment and reduce compatibility issues. Customer service has been great as well!
Kit is a great solution to add CarPlay capability while retaining the OEM radio. All the original features are still there while many new features are added by CarPlay. Audio through the AUX port seems to sound better than through the head unit's iPod and radio paths. It looks much better than an after-market radio since all the knobs and controls are still there. No ugly replacement panel that doesn't match your car's interior. No need to buy an additional module to the get back the camera and steering wheel controls. Customer service and technical support is excellent.
